Home » Products » DTH drilling rig » YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor
YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor

loading

YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor
YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor
YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor
YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor

YL920 25meter DTH Blast Hole Drilling Rig Rock Drilling Machine Crawler type using with diesel air compressor

5 0 Reviews

Availability:
Inquire Add to Basket
YUCHAI 58KW
Product Description
Separated Drilling Rig KZ-920
Engine
Yuchai YC4DK80 58kW
Drill Pipe Size
Φ64mm*3000mm
Hole Range
Φ80-115mm
Hole Depth(Max.)
25m
Rotation Torque(Max.)
1400N.m
Rotation Speed
0-70rpm
Feed Force
15kN
Pull Up Force
25kN
Feed Type
Hydraulic cylinder-chain
Tramming Speed(Max.)
2km/h
Gradient
30°
Total Weight
4200kg
(L*W*H)Transportation Dimensions
5300x2200x2050mm
