Product Description
name
YLCG35-30
compressor
Type
Twostageoilcompressionscrew
Exhaust volume
m³/min
40/35
Exhaustpressure
bar
22/30
Driving mode
Coupling direct coupling, diesel engine drive
Oil and gas tank capacity
L
210
Lubricating oil quantity
L
100
engine
manufacturer
cummins
model
QSZ13-C550-30
Form
6-cylinder
Number of cylinders
6
Rated power
kw
410
Rated speed
rpm
1800/1850
No load speed
rpm
1350
Lubricating oil quantity
L
32
Cooling water volume
L
80
Battery
6-QW-220MF*2
Fuel tank capacity
L
420
crew
Long (body / complete machine)
mm
4200
wide
mm
2000
high
mm
2350
Net weight
Kg
5300
Outlet vent valve
”1-G2” 1-G1”
name
YLCG35-30
compressor
Type
Twostageoilcompressionscrew
Exhaust volume
m³/min
40/35
Exhaustpressure
bar
22/30
Driving mode
Coupling direct coupling, diesel engine drive
Oil and gas tank capacity
L
210
Lubricating oil quantity
L
100
engine
manufacturer
cummins
model
QSZ13-C550-30
Form
6-cylinder
Number of cylinders
6
Rated power
kw
410
Rated speed
rpm
1800/1850
No load speed
rpm
1350
Lubricating oil quantity
L
32
Cooling water volume
L
80
Battery
6-QW-220MF*2
Fuel tank capacity
L
420
crew
Long (body / complete machine)
mm
4200
wide
mm
2000
high
mm
2350
Net weight
Kg
5300
Outlet vent valve
”1-G2” 1-G1”
