Home » Products » Water Well Drilling Rig » China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400

loading

China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400
China Water Well Drilling Rigs YLSJ400 China Water Well Drilling Rigs YLSJ400

China Water Well Drilling Rigs YLSJ400

5 0 Reviews

Availability:
Inquire Add to Basket
China 92Kw Six-Cylinder Turbocharging Heavy Duty Water Well Drilling Rigs For Sale
Product Description
Maximum borehole depth
400m
Hole diameter
105-381mm
Working wind pressure
1.05-3.45Mpa
Air consumption
16-55m³/min
Length of drill pipe
3m 4.5m 6m
Drill pipe diameter
89/102/114mm
Axial pressure
12T
Lifting force
26T
Single advance length
6.6m
Lifting speed
3.0m/min
Propulsion speed
0.5-5m/min
Rapid rise rate
25m/min
Fast forward speed
40m/min
Maximum turning torque
8500-11000Nm
Rotational speed
45-150r/min
Tool lifting force
2T
Mud pump flow
20L/min (optional）
High hydraulic leg stroke
1.55m
Footage efficiency
10-35m/h
Walking speed
3.5Km/h
Climbing ability
30°
Machine weight
10T
Overall dimension
3.6M×1.7M×2.15M
Engine
Yuchai 92kw (six cylinder turbocharged)
Adaptive condition
Loose layer and bedrock
Drilling mode
Top drive hydraulic rotation and propulsion, DTH impactor or mud drilling
