Home » Products » Water Well Drilling Rig » China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500

loading

China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500
China Water Well Drilling Rigs YL500 China Water Well Drilling Rigs YL500

China Water Well Drilling Rigs YL500

5 0 Reviews

Availability:
Inquire Add to Basket
Manufacturer Wholesale Price 130 Kw 6 Cylinder Portable Water Well Drilling Rig
Product Description
Maximum drilling depth
500 m
The hole diameter
105-350 - mm
The work of wind pressure
1.05-4.5 Mpa
Gas consumption
16 - after 60 m/min
Drill pipe length
3 m, 4.5 m, 6 m
Drill pipe diameter
89/102/114 mm
Axis pressure
12 t
Lifting force
28 t
Speed
3.0 m/min
The advance speed
0.5 5 m/min
Fast lifting speed
25 m/min
Fast-forward speed
40 m/min
Maximum turning torque
8500-11000 nm
The rotary speed
75-150 r/min
Tool lifting lifting force
1.5 T
Mud pump flow
20L/min (optional）
High hydraulic leg stroke
1.65 m
Penetration efficiency
10 to 35 m/h
Walking speed
3.5 Km/h
Climbing ability
21 °
Machine weight
11.5 T
Engine
Cummins 130 kw (6 cylinder)
Adaptive condition
Loose layer and bedrock
Drilling mode
Top drive hydraulic rotation and propulsion, DTH impacter or mud drilling
